BORN TOMORROW.

BORN TOMORROW.

Modern classic styling and cross-plane concept twin for fun performance, all built to be uniquely customized.

HIGHLIGHTS:
• Standout Style
• Advanced Crossplane Crankshaft Concept Engine
• Powerful Braking with ABS
• Compact, Sporty Chassis

The XSR700™ blends Yamaha's world-class engineering with timeless style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn't sacrifice performance. Drawing influence from Yamaha's classic "XS" series of motorcycles, the XSR® oozes class with its exposed aluminum details, retro-influenced bodywork, stepped seat, and custom lighting and instrumentation.

The compact 2-cylinder engine provides a unique power character with its outstanding torque and throttle response and is complemented with strong high-rpm pulling power. It also features Yamaha's "Crossplane Concept" 270-degree crank that provides linear torque development in response to the rider's throttle input. To reduce vibration and provide a smooth, modern engine character, the motor uses a geared counterbalancer that is mounted low and forward on the engine.

The XSR700™ provides exceptional and confident braking power thanks to its modern brake components which are backed up by the security of ABS.

The narrow frame design features sport-oriented geometry to achieve light and nimble handling and is aided by the minimalist 410-pound wet weight and refined ergonomics. A tall, wide handlebar, stitched two-level seat, and perfectly placed foot controls provide a comfortable upright riding position that is ideal for either urban traffic or hustling down a twisty road.

COLOR OPTION:
• Radical White/Rapid Red

Manufacturer's Suggested Retail Price (MSRP) shown. Does not include tax, title, prep, or destination charges. Actual prices set by dealer. Specifications subject to change without notice. This overview contains many of Yamaha's valuable trademarks. It may also contain trademarks belonging to other companies. Any references to other companies or their products are for identification purposes only and are not intended to be an endorsement. © 2020 Yamaha Motor Corporation, U.S.A. All rights reserved.

ENGINE
Engine Type 689cc liquid-cooled DOHC inline twin cylinder 8 valves
Bore x Stroke 80.0mm x 68.6mm
Compression Ratio 11.5 to 1
Fuel Delivery Fuel injection
Ignition TCI - Transistor Controlled Ignition
Transmission Constant mesh 6-speed, multi-plate wet clutch
Final Drive Chain
CHASSIS
Front Suspension 41mm telescopic fork 5.1-in travel
Rear Suspension Single shock, adjustable preload 5.1-in travel
Front Brakes Dual hydraulic disc, 282mm ABS
Rear Brakes Hydraulic disc, 245mm ABS
Front Tires 120/70ZR17 Pirelli® Phantom Sportcomp
Rear Tires 180/55ZR17 Pirelli® Phantom Sportcomp
DIMENSIONS
L x W x H 81.7 in x 32.3 in x 44.5 in
Seat Height 32.9 in
Wheelbase 55.3 in
Rake (Caster Angle) 25.0°
Trail 3.5 in
Maximum Ground Clearance 5.5 in
Fuel Capacity 3.7 gal
Fuel Economy 58 mpg
Wet Weight 410 lb
