| ENGINE | |
|---|---|
| Engine Type | 686cc liquid-cooled SOHC 4-stroke 4 valves |
| Bore / Stroke | 102.0mm x 84.0mm |
| Compression Ratio | 10.0 to 1 |
| Fuel Delivery | Yamaha Fuel Injection (YFI), 44mm |
| Ignition | TCI - Transistor Controlled Ignition |
| Starting System | Electric |
| Transmission | 5-speed w/reverse wet multi-plate clutch |
| Final Drive | X-ring chain 2WD |
| CHASSIS | |
| Front Suspension | Independent double wishbone w/piggyback high/low-speed compression, rebound and threaded preload adjustment, 9.1-in travel |
| Rear Suspension | Cast aluminum swingarm w/piggyback high/low-speed compression, rebound and threaded preload adjustment, 10.1-in travel |
| Front Brakes | Dual hydraulic disc |
| Rear Brakes | Hydraulic disc |
| Front Tires | AT22 x 7-10 Maxxis® |
| Rear Tires | AT20 x 10-9 Maxxis® |
| DIMENSIONS | |
| L x W x H | 72.6 in x 45.5 in x 43.9 in |
| Seat Height | 32.7 in |
| Wheelbase | 50.4 in |
| Maximum Ground Clearance | 9.5 in |
| Fuel Capacity | 2.9 gal |
| Wet Weight | 422 lbs |
| Lighting | Dual 30W Krypton headlights and LED brake light |
