| Engine & Drivetrain | |
|---|---|
| Cooling | Liquid |
| Cylinders Displacement | 925cc |
| Drive System Type | Isolated Xtreme Performance True On-Demand AWD/2WD |
| Engine Braking System (EBS) | Not Equipped |
| Engine Type | 4-Stroke DOHC Twin Cylinder Turbocharged |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 181 HP |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H |
| Dimensions | |
| Bed Box Dimensions (L x W x H) | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
| Box Capacity | 300 lb (136.1 kg) |
| Estimated Dry Weight | 2,020 lb (916 kg) |
| Fuel Capacity | 13 gal (49.2 L) |
| Ground Clearance | 14.5 in (36.8 cm) |
| Overall Vehicle Size (L x W x H) | 155 x 64 x 73.6 in (393.7 x 162.6 x 186.9 cm) |
| Payload Capacity | 900 lb (408 kg) |
| Wheelbase | 125 in (317.5 cm) |
| Brakes | |
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Dual-Bore Rear Calipers |
| Parking Brake | Park In-Transmission |
| Additional Specifications | |
| Cargo System | Lock & Ride |
| Doors | Front and Rear 1/2 Door |
| Hitch Towing Rating | N/A |
| Hitch Type | N/A |
| Instrumentation | Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center; User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Lighting | Signature Blacked Out White LED Low/High & Red LED Tail / Brake Lights |
| Seat Type | Front Bolstered Bucket Seats with 4-way adjustability (including 6 in front to back toolless seat sliders with tilt adjustability), Rear Stadium Style Seating with Height Adjustable Seat Belts |
| Tires / Wheels | |
| Electronic Power Steering | High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel |
| Front Tires | 30 x 10-14 Maxxis Carnivore II; (8-ply rated); Wheel Size 14x6 |
| Rear Tires | 30 x 10-14 Maxxis Carnivore II; (8-ply rated); Wheel Size 14x7 |
| Wheels | Cast Aluminum |
| Suspension | |
| Front Shocks | 2 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Front Suspension | High-Clearance Dual A-Arm with Stabilizer Bar and 20 in (50.8 cm) Usable Travel*, 17 in (43.2 cm) Wheel Travel |
| Rear Shocks | 2.5 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Rear Suspension | Trailing Arm & High-Clearance Radius Rods with Stabilizer Bar and 22 in (55.9 cm) Usable Travel*, 20 in (50.8 cm) Wheel Travel |
