Engine & Drivetrain |
|
Cooling |
Liquid |
Cylinders Displacement |
925cc |
Drive System Type |
Isolated Xtreme Performance True On-Demand AWD/2WD |
Engine Braking System (EBS) |
Not Equipped |
Engine Type |
4-Stroke DOHC Twin Cylinder Turbocharged |
Fuel System/Battery |
Electronic Fuel Injection |
Horsepower |
168 HP |
Transmission/Final Drive |
Automatic PVT P/R/N/L/H |
Dimensions |
|
Bed Box Dimensions (L x W x H) |
28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Box Capacity |
300 lb (136.1 kg) |
Estimated Dry Weight |
1,943 lb (881 kg) |
Fuel Capacity |
9.5 gal (35.9 L) |
Ground Clearance |
16 in (40.6 cm) |
Overall Vehicle Size (L x W x H) |
149 x 72 x 76 in (378.5 x 182.8 x 193 cm) |
Payload Capacity |
900 lb (408 kg) |
Wheelbase |
117 in (297.2 cm) |
Brakes |
|
Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front and Dual-Bore Rear Calipers |
Parking Brake |
Park In-Transmission |
Additional Specifications |
|
Cargo System |
Lock & Ride |
Doors |
Bowed 1/2 Doors |
Instrumentation |
Dual-sweep Analog Dials w/ 4" LCD Rider Information Center |
Lighting |
Signature Blacked Out White LED Low/High & Red LED Tail / Brake Lights |
Seat Type |
Bolstered Bucket Seats with Seat Slider and SubZero 4-point harness |
Tires / Wheels |
|
Electronic Power Steering |
Xtreme Performance with Quick Turn Rack |
Front Tires |
32 x 10-15; ITP COYOTE (8-Ply Rated) |
Rear Tires |
32 x 10-15; ITP COYOTE (8-Ply Rated) |
Wheels |
Cast Aluminum |
Suspension |
|
Front Shocks |
Walker Evans® 2.5” Velocity Needle Shocks with 16-Position Adjustable Clickers |
Front Suspension |
Dual A-Arm with Stabilizer Bar and 25 in (63.5 cm) Usable Travel*, 19 in (48.2 cm) of Wheel Travel |
Rear Shocks |
Walker Evans® 3.0” Velocity Needle Shock with 16-Position Adjustable Clickers |
Rear Suspension |
Trailing Arm with Stabilizer Bar and 25 in (63.5 cm) Usable Travel*, 21 in (53.3 cm) of Wheel Travel |
