| Engine & Drivetrain | |
|---|---|
| Cooling | Liquid |
| Cylinders Displacement | 999cc |
| Drive System Type | High Performance True On-Demand AWD/2WD |
| Engine Braking System (EBS) | Standard |
| Engine Type | 4-Stroke DOHC Twin Cylinder |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 100 HP |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H |
| Dimensions | |
| Bed Box Dimensions (L x W x H) | 20.7 x 37 x 7.9 in (52.5 x 94 x 20 cm) |
| Box Capacity | 300 lb (136 kg) |
| Estimated Dry Weight | 1,255 lbs (560 kg) |
| Fuel Capacity | 9.5 gal (35.9 L) |
| Ground Clearance | 12.5 in (31.8 cm) |
| Overall Vehicle Size (L x W x H) | 108 x 60 x 72 in (274.3 x 152.4 x 182.9 cm) |
| Payload Capacity | 740 lb (336 kg) |
| Wheelbase | 79 in (200.7 cm) |
| Brakes | |
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Park In-Transmission |
| Additional Specifications | |
| Cargo System | Lock & Ride |
| Doors | Bowed 1/4 Doors |
| Hitch Towing Rating | 1,500 lb (680.4 kg) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Instrumentation | Single Analog Dial with 2 in LCD Rider Information Center, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Volt Meter, Service Indicator and Codes, Seatbelt Reminder Light, Gear Indicator, DC Outlet |
| Lighting | Halogen, 55W low/ 60W high, Red LED Tail/Brake Lights |
| Seat Type | Bolstered Bucket Seats with Driver Seat Slider |
| Tires / Wheels | |
| Electronic Power Steering | Not Equipped |
| Front Tires | 27 x 9-12; GBC Dirt Commander |
| Rear Tires | 27 x 11-12; GBC Dirt Commander |
| Wheels | Cast Aluminum |
| Suspension | |
| Front Shocks | 2 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Front Suspension | Dual A-Arm with Stabilizer Bar and 12.25 in (31.1 cm) Wheel Travel |
| Rear Shocks | 2 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Rear Suspension | Dual A-Arm with Stabilizer Bar and 13.2 in (33.5 cm) Wheel Travel |
