Engine & Drivetrain |
|
Cooling |
Liquid |
Cylinders Displacement |
999cc |
Drive System Type |
Isolated Xtreme Performance True On-Demand AWD/2WD |
Engine Braking System (EBS) |
Not Equipped |
Engine Type |
4-Stroke DOHC Twin Cylinder |
Fuel System/Battery |
Electronic Fuel Injection |
Horsepower |
110 HP |
Transmission/Final Drive |
Automatic PVT P/R/N/L/H |
Dimensions |
|
Bed Box Dimensions (L x W x H) |
20.5 x 23 x 4 /1 in (Front/Rear) (52 x 58 x 10.4 / 3 cm (Front/Rear) |
Box Capacity |
50 lb (22.6 kg) |
Estimated Dry Weight |
1,383 lbs (627 kg) |
Fuel Capacity |
9.5 gal (35.9 L) |
Ground Clearance |
13 in (33 cm) |
Overall Vehicle Size (L x W x H) |
112 x 64 x 73.75 in (284.5 x 162.6 x 187.3 cm) |
Payload Capacity |
300 lb (136.1kg) |
Wheelbase |
83 in (211 cm) |
Brakes |
|
Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front and Dual-Bore Rear Calipers |
Parking Brake |
Park In-Transmission |
Additional Specifications |
|
Doors |
LH-Door |
Instrumentation |
Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center; User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
Lighting |
Signature Blacked Out White LED Low/High & Red LED Tail / Brake Lights |
Seat Type |
Bolstered Bucket Seat with Seat Slider and Rear Height Adjustable Seat Belt |
Tires / Wheels |
|
Front Tires |
29 x 9-14; Radial Tire |
Rear Tires |
29 x 11-14; Radial Tire |
Wheels |
Cast Aluminum |
Suspension |
|
Front Shocks |
2 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Front Suspension |
Dual A-Arm with Stabilizer Bar and 21 in (53.4 cm) Usable Travel*, 16 in (40.6 cm) of Wheel Travel |
Rear Shocks |
2.5 in Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Rear Suspension |
Trailing Arm with Stabilizer Bar and 21 in (53.4 cm) Usable Travel*, 18 in (45.7 cm) of Wheel Travel |
