| Engine & Drivetrain | |
|---|---|
| Cooling | Liquid |
| Cylinders Displacement | 999cc |
| Drive System Type | High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode |
| Engine Type | 4-Stroke Single Cylinder DOHC |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 82 HP |
| Transmission/Final Drive | Automatic PVT H/L/N/R/P; Shaft |
| Dimensions | |
| Bed Box Dimensions (L x W x H) | 36.75 x 54.25 x 12.5 in (93.3 x 137.8 x 31.75 cm) |
| Box Capacity | 1,000 lb (453.6 kg) |
| Estimated Dry Weight | 1,955 lb (887 kg) |
| Fuel Capacity | 11.5 gal (43.5 L) |
| Ground Clearance | 14 in (35.6 cm) |
| Overall Vehicle Size (L x W x H) | 120 x 65 x 79.5 in. (305 x 165 x 202 cm) |
| Seating Cpacity | 3 |
| Wheelbase | 81 in (206 cm) |
| Brakes | |
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Hand-Actuated |
| Additional Specifications | |
| Cargo System | Lock & Ride |
| Hitch Towing Rating | 2,500 lb (1,133.9 kg) |
| Hitch Type | Standard 2 in (5 cm) Receiver |
| Instrumentation | Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center; User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet |
| Lighting | Halogen Headlamps, 55W Low Beam, 60W High Beam, Dual LED Taillamps |
| Tilt Steering | Standard |
| Tires / Wheels | |
| Electronic Power Steering | Standard |
| Front Tires | 29 x 9-14; Maxxis MU511 |
| Rear Tires | 29 x 11-14; Maxxis MU521 |
| Wheels | 14 in Black Aluminum |
| Suspension | |
| Front Suspension | Independent, Arched Lower A-arms, 10 in (25.4 cm) of Travel |
| Rear Suspension | Independent, Arched Lower A-arms, Nivomat Load-Adaptive, 10 in (25.4 cm) of Travel |
