Engine |
|
Bore |
85 mm |
Stroke |
74 mm |
Cylinders-Displacement (cc) |
2 - 840 cc |
Cooling |
Liquid Cooled |
Exhaust |
Single, 3 Stage VES w/ Smart Actuator |
Fuel System |
Cleanfire® Injection |
Ignition |
Patriot™ 3DS |
Drivetrain |
|
Drive System |
QuickDrive™ |
Drive/Driven Clutch |
P-85 / TEAM® LWT |
Suspension |
|
Front Shocks |
WER® Velocity Hi-Lo |
Front Suspension |
AXYS® RMK® React™ |
Front Track Shock |
WER® 2 |
Front Travel (in./cm.) |
9 in (22.9 cm) |
Rear Suspension |
RMK® KHAOS® |
Rear Track Shock |
WER® Velocity Hi-Lo |
Rear Travel (in./cm.) |
16 in (40.6 cm) |
Brakes |
|
Disc Brake Type |
AXYS® RMK® LWT |
Dimensions |
|
Overall Height |
49.1 in (124.7 cm) |
Overall Length |
131 in (332.75 cm) |
Overall Width |
43.5 in (110.5 cm) |
Ski Center Distance (in./cm.) |
36 - 37 - 38 in (91.4 - 93.9 - 96.5 cm) |
Track (WxLxH in.) |
15 x 155 x 2.6 in Series 6 |
Capacities |
|
Fuel Capacity |
11.5 gal (43.5 L) |
Seating Capacity |
1 |
Weights |
|
Estimated Dry Weight (lbs./kgs.) |
420 lb (191 kg) |
Color |
|
Color/Graphics |
Polaris Blue, Black, Matte Sunset Red |
Features |
|
Ski Type |
Gripper |
12v-DC Outlet / RCA Outlet |
Accessory |
Electric Start |
Option |
Fuel Gauge Type |
Mechanical |
Hand & Thumb Warmers |
Standard Adjustable |
Handlebars |
Low-Rise ProTaper, Mid-Rise ProTaper, High-Rise ProTaper |
Mirrors |
Accessory |
Reverse |
PERC® |
Seat Type |
PRO-LITE |
Security System |
Option / Accessory |
Speedometer |
Polaris® MessageCenter Gauge, Polaris® Interactive Digital Display |
Tachometer |
Polaris® MessageCenter Gauge, Polaris® Interactive Digital Display |
Temp/Low Oil Light |
Polaris® MessageCenter Gauge, Polaris® Interactive Digital Display |
Windshield |
AXYS® Low 7 IN Black / AXYS® Deep Snow Mid 13 IN Gloss Black |
Features |
Storage |
