| Engine | |
|---|---|
| Bore | 85 mm |
| Stroke | 74 mm |
| Cylinders-Displacement (cc) | 2 - 840 cc |
| Cooling | Liquid Cooled |
| Exhaust | Single, 3 Stage VES |
| Fuel System | Cleanfire® Injection |
| Ignition | Patriot™ 3DS |
| Drivetrain | |
| Drive System | Chaincase |
| Drive/Driven Clutch | P-85 / TEAM® LWT |
| Suspension | |
| Front Shocks | WER® Velocity |
| Front Suspension | MATRYX Front Suspension |
| Front Track Shock | WER® 2 IN C/A |
| Front Travel (in./cm.) | 9.3 in (23.6 cm) |
| Rear Suspension | PRO-CC™ |
| Rear Track Shock | WER® Velocity |
| Rear Travel (in./cm.) | 16.2 in (41.1 cm) |
| Brakes | |
| Disc Brake Type | MATRYX Stealth |
| Dimensions | |
| Overall Height | 46 in (116.8 cm) |
| Overall Length | 117 in (297.2 cm) |
| Overall Width | 47 in (119.4 cm) |
| Ski Center Distance (in./cm.) | 42.5 in (108 cm) |
| Track (WxLxH in.) | 15 x 129 x 1.25 Ice Ripper XT / 15 x 129 x 1.35 Cobra / 15 x 129 x 1.5 Storm 150 |
| Capacities | |
| Fuel Capacity | 11.5 gal (43.5 L) |
| Seating Capacity | 1 |
| Weights | |
| Estimated Dry Weight (lbs./kgs.) | 467 lb (212 kg) |
| Color | |
| Color/Graphics | Black w/Stealth Gray, Indy Red w/White Lightning, Black w/Indy Red, Black w/White Lightning, Stealth Gray w/Black Turbo Silver w/Polaris Blue Turbo Silver w/Indy Red |
| Features | |
| Ski Type | PRO-STEER |
| 12v-DC Outlet / RCA Outlet | Accessory |
| Electric Start | Option |
| Fuel Gauge Type | Electronic |
| Hand & Thumb Warmers | Smart Warmers |
| Handlebars | One Piece Hooked |
| Mirrors | Accessory |
| Reverse | PERC® |
| Seat Type | MATRYX Performance, Passenger- Accessory |
| Security System | Option / Accessory |
| Speedometer | Polaris 7S Digital Display |
| Tachometer | Polaris 7S Digital Display |
| Temp/Low Oil Light | Polaris 7S Digital Display |
| Windshield | Handguards, MATRYX Mid Smoke, MATRYX Tall Smoke |
| Features | |
| Storage | Standard, Rear Rack/Tow Hitch; Accessory |
