Engine & Drivetrain |
|
Cooling |
Liquid |
Cylinders Displacement |
499cc |
Drive System Type |
One Touch On-Demand AWD/2WD |
Engine Type |
Prostar 4-Stroke SOHC Single Cylinder |
Fuel System/Battery |
Electronic Fuel Injection / 340 CCA |
Horsepower |
33 HP |
Transmission/Final Drive |
Automatic PVT P/R/N/L/H In-line Shifting |
Dimensions |
|
Estimated Dry Weight |
700 lbs. (317.5 kg) |
Front/ Rear Rack |
90 lb /180 lb (40.8 kg /81.6 kg) |
Fuel Capacity |
4.5 gal (17.0 L) |
Ground Clearance |
11.5 in (29 cm) |
Overall Vehicle Size (L x W x H) |
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm) |
Payload Capacity |
485 lb (220 kg) |
Seat Height |
33.25 in (84.5 cm) |
Wheelbase |
50.5 in (128.3 cm) |
Brakes |
|
Front/Rear Brakes |
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake |
Park In-Transmission / Lockable Hand Lever |
Additional Specifications |
|
Cargo System |
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
Front Suspension |
Sealed MacPherson Strut With 8.2 in (20.8 cm) Travel |
Rear Suspension |
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel |
Hitch Towing Rating |
1,350 lb (612 kg) |
Hitch Type |
Standard 1.25 in (3.2 cm) Receiver |
Instrumentation |
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light |
Lighting |
Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Single LED Brake Light/Taillight |
Tires / Wheels |
|
Electronic Power Steering |
Not Equipped |
Front Tires |
25x8-12 P373; 6 PLY |
Rear Tires |
25x10-12 P373; 6 PLY |
Wheels |
Steel |
