POWER |
|
Engine |
4-stroke, SOHC, 4-valve V-twin, liquid-cooled |
Displacement |
783cc |
Bore x Stroke |
85.0 x 69.0mm |
Compression Ratio |
10.7 |
Maximum Torque |
47.0 lb-ft@ 5500 rpm |
Fuel System |
DFI® with two 36mm Mikuni throttle bodies |
Ignition |
TCBI with electronic advance |
Starting System |
Electric |
Transmission |
Automatic CVT with centrifugal clutch (H,L,N,R) |
Final Drive |
Selectable 2WD/4WD with locking front differential, shaft |
Engine Braking |
Yes |
CAPABILITY |
|
Front Suspension / Wheel Travel |
Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.0 in. |
Rear Suspension / Wheel Travel |
Double Wishbone; Fox Podium coil-over shocks with piggyback reservoir, adjustable preload and 24-way compression damping/8.3 in. |
Front Tires |
Maxxis 26 x 9-12 |
Rear Tires |
Maxxis 26 x 11-12 |
Steering |
Electric Power Steering (EPS) / rack-and-pinion |
Front Brakes |
Dual hydraulic discs with two-piston calipers |
Rear Brakes |
Sealed, oil-bathed, multi-disc |
Ground Clearance |
11.2 in |
Fuel Capacity |
7.9 gal |
Turning Radius |
16.7 ft |
Cargo Bed Dimensions (LxWxH) |
17.9 x 47.6 x 8.7 in |
Cargo Bed Capacity |
249 lb |
Load Capacity |
1109 lb |
Seating Capacity |
4 |
Towing Capacity |
1300 lb |
Lighting |
(4) LED headlights, (2) LED taillights, LED stoplight |
DETAILS |
|
Frame |
Steel Tube Double-X Reinforcement |
Overall Length |
125.4 in |
Overall Width |
60.0 in |
Overall Height |
79.7 in |
Curb Weight |
1622.9 lb |
Wheelbase |
85.6 |
Wheel Type |
Steel |
