POWER |
|
Engine |
4-stroke, DOHC, 8-valve parallel-twin, liquid cooled |
Displacement |
999cc |
Bore x Stroke |
92.0 x 75.1 mm |
Compression Ratio |
11.5 to 1 |
Maximum Torque |
76.7 lb-ft @ 7000 rpm |
Fuel System |
DFI with two 50mm throttle bodies |
Ignition |
TCBI with electronic advance |
Starting System |
Electric |
Transmission |
Automatic CVT with centrifugal clutch (H,L,N,R) |
Final Drive |
Selectable 2WD/4WD with locking front differential, shaft |
Engine Braking |
Yes |
CAPABILITY |
|
Front Suspension / Wheel Travel |
Double wishbone, FOX 2.5 Podium Live Valve Internal Bypass shocks with piggyback reservoir, fully adjustable preload, and KECS controlled compression damping/18.6 in. |
Rear Suspension / Wheel Travel |
4-link trailing-arm rear suspension, FOX 2.5 Podium Live Valve Internal Bypass shocks with piggyback reservoir, fully adjustable preload, and KECS controlled compression damping/21.1 in. |
Front Tires |
MAXXIS Carnivore 31 x 10.00R15 8PR |
Rear Tires |
MAXXIS Carnivore 31 x 10.00R15 8PR |
Steering |
Electric Power Steering (EPS) / rack-and-pinion |
Front Brakes |
Dual hydraulic discs with two-piston calipers |
Rear Brakes |
Dual hydraulic discs with single-piston calipers |
Ground Clearance (Min/Max) |
14.0 in / 14.4 in |
Fuel Capacity |
10.6 gal |
