POWER |
|
Engine |
4-stroke, DOHC, 8-valve parallel-twin, liquid cooled |
Displacement |
999cc |
Bore x Stroke |
92.0 x 75.1 mm |
Compression Ratio |
11.5 |
Maximum Torque |
76.7 lb-ft @ 7000 rpm |
Fuel System |
DFI with two 50mm throttle bodies |
Ignition |
TCBI with electronic advance |
Starting System |
Electric |
Transmission |
Automatic CVT with centrifugal clutch (H,L,N,R) |
Final Drive |
Selectable 2WD/4WD with locking front differential, shaft |
Engine Braking |
Yes |
CAPABILITY |
|
Front Suspension / Wheel Travel |
Double wishbone, FOX® 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compression damping/18.6 in. |
Rear Suspension / Wheel Travel |
4-link trailing-arm rear suspension, FOX® 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compre |
Front Tires |
MAXXIS Carnivore 31 x 10.00R15 8PR |
Rear Tires |
MAXXIS Carnivore 31 x 10.00R15 8PR |
Steering |
Electric Power Steering (EPS) / rack-and-pinion |
Front Brakes |
Dual hydraulic discs with two-piston calipers |
Rear Brakes |
Dual hydraulic discs with single-piston calipers |
Ground Clearance |
14.4 in |
Fuel Capacity |
10.6 gal |
Turning Radius |
20.3 ft |
Cargo Bed Dimensions (LxWxH) |
14.6 x 33.1 x 9.1 in |
Cargo Bed Capacity |
351 lbs |
Load Capacity |
781 lbs |
Seating Capacity |
2 |
Towing Capacity |
N/A |
Lighting |
(2) LED headlights, (2) LED taillights, LED stoplight |
DETAILS |
|
Frame |
Ladder type, tubular steel |
Overall Length |
130.1 in |
Overall Width |
68.1 in |
Overall Height |
75.0 in |
Curb Weight |
1896.3 lbs (1898.5 CA) |
Wheelbase |
98.8 in |
Wheel Type |
Alloy with bead-lock wheels |
