POWER |
|
Engine |
4-stroke, single cylinder, SOHC, 4-valve liquid-cooled |
Displacement |
695cc |
Bore x Stroke |
102.0 x 85.0 mm |
Compression Ratio |
10.3 |
Maximum Torque |
42.7 lb-ft @ 5000 rpm |
Fuel System |
DFI® with 44mm throttle body |
Transmission |
Continuously Variable Transmission (CVT) with centrifugal clutch, (H,L,N,R) |
Final Drive |
Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock |
Engine Braking |
Yes |
Alternator Output (max) |
35.7 amp |
CAPABILITY |
|
Front Suspension / Wheel Travel |
Double wishbone/8.6 in |
Rear Suspension / Wheel Travel |
Double wishbone/9.1 in |
Front Tires |
25x8.00-12, radial |
Rear Tires |
25x10.00-12, radial |
Park Brake Type |
Independent, Mechanical Disc |
Steering |
Electric Power Steering (EPS), Tilt steering |
Front Brakes |
Dual Disc, 2 piston caliper |
Rear Brakes |
Dual Disc, 1 piston caliper |
Ground Clearance |
10.6 in |
Fuel Capacity |
9.5 gal |
Turning Radius |
14.0 ft |
Cargo Bed Dimensions (LxWxH) |
33.4 x 44.1 x 9.1 in |
Cargo Bed Capacity |
699 lb (600 lb California models) |
Load Capacity |
1200 lb |
Seating Capacity |
2 |
Towing Capacity |
1500 lb |
Lighting |
(2) Halogen headlights. (2) LED headlights |
DETAILS |
|
Overall Length |
110.0 in |
Overall Width |
60.0 in |
Overall Height |
74.4 in |
Curb Weight |
1587.6 lb |
Wheelbase |
78.9 in |
Wheel Type |
Steel |
