POWER |
|
Engine |
4-stroke, 3-cylinder, OHV, liquid-cooled, diesel |
Displacement |
993cc |
Bore x Stroke |
2.91x3.03 in |
Compression Ratio |
23.5 |
Maximum Torque |
38.3 lb-ft @ 2400 rpm |
Fuel System |
Bosch in-line injection pump |
Transmission |
Continuously Variable Transmission (CVT) with (H,L,N,R) |
Final Drive |
Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock |
Engine Braking |
Yes |
Alternator Output (max) |
55 amp |
CAPABILITY |
|
Front Suspension / Wheel Travel |
Double wishbone/8.7 in |
Rear Suspension / Wheel Travel |
Double wishbone/8.5 (L) /8.7 (R) in |
Front Tires |
26x9.00-12 |
Rear Tires |
26x11.00-12 |
Park Brake Type |
Independent, Mechanical Disc |
Steering |
Electric Power Steering (EPS), Tilt steering |
Front Brakes |
Dual Disc, 2 piston caliper |
Rear Brakes |
Dual Disc, 1 piston caliper |
Ground Clearance |
10.2 in |
Fuel Capacity |
7.9 gal |
Turning Radius |
16.0 ft |
Cargo Bed Dimensions (LxWxH) |
42.7 x 53.7 x 11.0 in (3-person) 22.0 x 53.7 x 11.0 in (6-person) |
Cargo Bed Capacity |
1000 lb (3-person) 350 lb (6-person) |
Load Capacity |
1581 lb |
Seating Capacity |
3-person (1 row), 6 person (2 row) |
Towing Capacity |
2000 lb |
Lighting |
(2) Halogen headlights |
DETAILS |
|
Overall Length |
133.3 in |
Overall Width |
64.0 in |
Overall Height |
79.5 in |
Curb Weight |
1964.7 lb |
Wheelbase |
92.3 in |
Wheel Type |
Steel |
