ENGINE & DRIVETRAIN |
|
Engine |
4-stroke, 4-cylinder, DOHC, 4-valve |
Cooling |
Liquid |
Displacement |
998cc |
Bore x Stroke |
76.0 x 55.0mm |
Compression Ratio |
11.2-1 |
Fuel System |
DFI, 40mm Throttle Bodies |
Ignition |
TCBI w/ Digital Advance |
Fuel Capacity |
5.0 gal |
Transmission |
6-speed dog-ring, return shift |
Final Drive |
Sealed Chain |
ELECTRICAL |
|
Instrumentation |
Integrated Riding Modes, Kawasaki Cornering Management Function (KCMF), Power Modes (3), Kawasaki Launch Control Mode (KLCM), Kawasaki Traction Control (KTRC), Kawasaki Launch Control Mode (KLCM), Kawasaki Engine Brake Control (KEBC), Kawasaki Intelligent anti-lock Brake System (KIBS), Kawasaki Quick Shifter (KQS) (upshift & downshift), Electronic Cruise Control |
BRAKES/ WHEELS/ TIRE |
|
Front Suspension/ Wheel Travel |
Showa SFF-BP Fork with Adjustable Compression and Rebound Damping, Spring Preload Adjustability |
Rear Suspension/ Wheel Travel |
Uni-Trak®, Showa Gas-Charged Shock with Adjustable Compression and Rebound Damping, Preload Adjustability |
Front Brakes |
Dual 320mm Disc w/Radial-mount Brembo M4.32 Calipers, KIBS |
Rear Brakes |
Single 250mm disc with single-piston caliper, KIBS |
Front Tire |
120/70-17 |
Rear Tire |
190/55-17 |
DIMENSIONS |
|
Curb Weight |
527.0 lb |
Rake/ Trail |
24.9°/4.1in |
Length |
82.1 in |
Height |
44.5 in |
Width |
31.9 in |
Ground Clearance |
5.5 in |
Wheelbase |
57.3 in. |
Seat Height |
32.7 in |
