ENGINE & DRIVETRAIN |
|
Engine |
4-stroke, 55-degree V-twin |
Cooling |
Liquid |
Displacement |
903cc |
Bore x Stroke |
88.0 x 74.2mm |
Compression Ratio |
9.5-1 |
Fuel System |
DFI 34mm Throttle Bodies (2), with sub-throttle valves |
Ignition |
TCBI with electronic advance |
Fuel Capacity |
5.3 gal |
Transmission |
5-speed with positive neutral finder |
Final Drive |
Kevlar-reinforced belt |
BRAKES/ WHEELS/ TIRE |
|
Front Suspension/ Wheel Travel |
41mm telescopic fork/5.9 in |
Rear Suspension/ Wheel Travel |
Uni-Trak® swingarm, 7-way adjustable spring preload/4.1 in |
Front Brakes |
Single 300mm hydraulic disc |
Rear Brakes |
Single 270mm hydraulic disc |
Front Tire |
130/90-21 |
Rear Tire |
180/70-15 |
DIMENSIONS |
|
Curb Weight |
610.8 lb |
Rake/ Trail |
33°/7.2 in |
Length |
94.7 in |
Height |
44.1 in |
Width |
35.2 in |
Ground Clearance |
5.5 in |
Wheelbase |
64.8 in. |
Seat Height |
27.0 in |
