ENGINE & DRIVETRAIN |
|
Engine |
4-stroke, 52-degree V-twin |
Cooling |
Liquid |
Displacement |
1700cc |
Bore x Stroke |
102.0 x 104.0mm |
Compression Ratio |
9.5-1 |
Fuel System |
DFI 42mm Throttle Bodies (2) |
Ignition |
TCBI with electronic advance |
Fuel Capacity |
5.3 gal |
Transmission |
6-speed with overdrive and positive neutral finder |
Final Drive |
Carbon fiber-reinforced belt |
ELECTRICAL |
|
Instrumentation |
Electronic cruise control, Kawasaki Advanced Coactive-Braking Technology (K-ACT II) ABS |
BRAKES/ WHEELS/ TIRE |
|
Front Suspension/ Wheel Travel |
45mm Showa telescopic fork/5.5 in |
Rear Suspension/ Wheel Travel |
Swingarm with twin air-assisted shocks, with 4-way rebound damping/3.1 in |
Front Brakes |
Dual 300mm discs, dual four-piston calipers, K-ACT II ABS |
Rear Brakes |
Single 300mm disc, twin-piston caliper, K-ACT II ABS |
Front Tire |
130/90-16 |
Rear Tire |
170/70-16 |
DIMENSIONS |
|
Curb Weight |
844.5 lb |
Length |
98.8 in |
Height |
50.8 in |
Width |
38.2 in |
Ground Clearance |
5.7 in |
Wheelbase |
65.5 in. |
Seat Height |
28.7 in |
