ENGINE & DRIVETRAIN |
|
Engine |
4-stroke, 4-cylinder, DOHC, 16-valve |
Cooling |
Liquid |
Displacement |
1043cc |
Bore x Stroke |
77.0 x 56.0mm |
Compression Ratio |
10.3-1 |
Fuel System |
DFI® with 38mm Keihin ETV throttle bodies (4) |
Ignition |
TCBI with electronic advance |
Fuel Capacity |
5.5 gal |
Transmission |
6-speed, return shift, Kawasaki Quick Shifter (KQS) |
Final Drive |
Sealed Chain |
ELECTRICAL |
|
Instrumentation |
Kawasaki Electronic Control Suspension (KECS), Integrated riding modes, Kawasaki Quick Shifter (KQS), Electronic cruise control and heated grips |
BRAKES/ WHEELS/ TIRE |
|
Front Suspension/ Wheel Travel |
43mm inverted fork with KECS-controlled rebound and compression damping, manual spring preload adjustability and top-out springs/5.9 in |
Rear Suspension/ Wheel Travel |
Horizontal back-link New Uni-Trak®, BFRC gas charged shock with piggyback reservoir, KECS-controlled compression and rebound damping electronically-adjustable spring preload/5.9 in |
Front Brakes |
Dual 310mm petal-style discs with four-piston calipers, ABS |
Rear Brakes |
Single 250mm petal disc with single-piston caliper, ABS |
Front Tire |
120/70 ZR-17 |
Rear Tire |
180/55 ZR-17 |
DIMENSIONS |
|
Curb Weight |
566.7 lb |
Rake/ Trail |
27°/4.0 in |
Length |
89.4 in |
Height |
58.7 in |
Width |
37.4 in |
Ground Clearance |
5.9 in |
Wheelbase |
59.8 in. |
Seat Height |
33.1 in |
|
|
