| ENGINE & DRIVETRAIN | |
|---|---|
| Engine | 4-stroke, In-Line Four, DOHC, 16-valve |
| Cooling | Liquid |
| Displacement | 636cc |
| Bore x Stroke | 67.0 x 45.1mm |
| Compression Ratio | 12.9-1 |
| Fuel System | DFI® w/38mm Keihin throttle bodies (4) and oval sub-throttles |
| Ignition | TCBI with digital advance |
| Fuel Capacity | 4.5 gal |
| Transmission | 6-speed, return shift |
| Final Drive | Sealed Chain |
| ELECTRICAL | |
| Instrumentation | Kawasaki Traction Control (KTRC), Power Mode, Kawasaki Intelligent anti-lock Brake System (KIBS), Kawasaki Quick Shifter (KQS) (upshift only) |
| BRAKES/ WHEELS/ TIRE | |
| Front Suspension/ Wheel Travel | 41mm inverted Showa SFF-BP fork with top-out springs, stepless compression and rebound damping, adjustable spring preload/4.7 in |
| Rear Suspension/ Wheel Travel | Bottom-link Uni-Trak® with gas-charged shock, stepless compression damping adjustment, 25-way adjustable rebound damping, fully adjustable spring preload/5.3 in |
| Front Brakes | Dual 310mm petal discs with dual radial-mounted, Nissin 4-piston, monobloc calipers and KIBS ABS |
| Rear Brakes | Single 210mm petal discs with single-piston caliper and KIBS ABS |
| Front Tire | 120/70 ZR17 |
| Rear Tire | 180/55 ZR17 |
| DIMENSIONS | |
| Curb Weight | 430.0 lb. |
| Rake/ Trail | 23.5°/4.0 in |
| Length | 79.7 in. |
| Height | 43.3 in. |
| Width | 28.0 in |
| Ground Clearance | 5.1 in |
| Wheelbase | 55.1 in. |
| Seat Height | 32.7 in |
