| ENGINE | |
|---|---|
| Engine Type | 999cc liquid-cooled Unicam® OHC longitudinally mounted parallel-twin four-stroke; four valves per cylinder |
| Bore and Stroke | 92mm x 75.1mm |
| Compression Ratio | 10-1 |
| Induction | Fuel Injection (PGM-FI), 46mm throttle body |
| Ignition | Full-transistorized with electronic advance |
| DRIVE TRAIN | |
| Transmission | Six-speed automatic Dual-Clutch Transmission (DCT) with high/low subtransmission. Two drive modes with 2WD and i-4WD. Three shift modes (standard, sport, manual w/ paddle shifters). |
| Driveline | Direct front and rear driveshafts |
| CHASSIS/ SUSPENSION/ BRAKES | |
| Front Suspension | Independent double-wishbone; 17.7 inches of travel |
| Rear Suspension | 4+ link trailing arm; 20.1 inches of travel |
| Front Brake | Dual 250mm hydraulic discs |
| Rear Brake | Dual 250mm hydraulic discs |
| Front Tires | 28 x 9-15 |
| Rear Tires | 28 x 11-15 |
| DIMENSIONS | |
| Length | 125.5 inches |
| Width | 68.4 inches |
| Height | 75.6 inches |
| Wheelbase | 92.7 inches |
| Bed Capacity | 299 pounds |
| Seat Height | 28.3 inches |
| Ground Clearance | 12.6 inches |
| Turning Radius | 21.3 feet |
| Curb Weight | 1630 pounds for 49 states - Includes all standard equipment, required fluids and full tank of fuel. |
| Fuel Capacity | 7.3 gallons, including 1.1-gallon reserve |
