ENGINE |
|
Engine Type |
Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic |
Displacement |
937 cc |
Bore x Stroke |
94 mm x 67.5 mm |
Cooling |
Liquid cooled |
Compression Ratio |
12.6 plus or minus 0.5 to1 |
Engine Power |
110 hp (81 kW) @ 9,000 rpm |
Engine Torque |
69 lb-ft (93 Nm) @ 6,500 rpm |
Fuel Injection |
Electronic fuel injection system, Æ 53 mm throttle bodies with full Ride-by-Wire |
Fuel Economy |
5.6 l/100 km |
TRANSMISSION |
|
Gearbox |
6 speed with Ducati Quick Shift (DQS) up/down EVO. |
Primary Drive |
Straight cut gears; Ratio 1.84 to 1 |
Final Drive |
Chain; Front sprocket 15; Rear sprocket 43 |
Clutch |
Slipper and self-servo wet multi-plate clutch with hydraulic control. Self bleeding master cylinder |
CHASSIS & SUSPENSION |
|
Frame Type |
Tubular steel Trellis frame attached to the cylinders head. |
Exhaust |
Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminum mufflers. |
Front Suspension |
|
Rear Suspension |
|
BRAKES/WHEELS/TIRES |
|
Front braking system |
3 x 320 mm semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with Bosch Cornering ABS. Self bleeding master cylinder |
Rear braking system |
245 mm disc, 2-piston caliper, Bosch Cornering ABS |
Front Wheel |
Y shaped, 3-spoke in light alloy 3.50" x 17" |
Rear Wheel |
Y shaped, 3-spoke in light alloy 5.50" x 17" |
Front Tire |
Pirelli Diablo Rosso III 120/70 ZR17 |
Rear Tire |
Pirelli Diablo Rosso III 180/55 ZR17 |
Front Wheel Travel |
130 mm (5.1 in) |
Rear Wheel Travel |
144 mm (5.7 in) |
DIMENSIONS |
|
Seat Height |
810 mm (31.9 in) |
Wheelbase |
1.478 mm (58.3 in) |
Rake/Trail |
24 ° |
Fuel Capacity |
16 l - 4.2 gallon |
Seating Capacity |
2 |
Weight |
Dry - 184 kg (405 lbs) |
