ENGINE |
|
Engine Type / Displacement - |
|
HD5 |
38 hp, Rotax® 427 cc single cylinder, liquid cooled / 427 |
HD8 |
50 hp / 50 lb-ft , Rotax® 799.9 cc, V-twin, liquid cooled / 799 |
HD10 |
82 hp / 69 lb-ft, Rotax® 976 cc, V-twin, liquid cooled / 976 |
Fuel Delivery System |
Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
Transmission - |
|
HD5 |
CVT, P / R / N / H / L, standard engine braking |
HD8 & HD10 |
PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection, Extra-L / H / N / R / P |
Drive Train - |
|
HD5 |
Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential |
HD8 & HD10 |
Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front differential |
Driving Assistance |
Electronic Hill Descent Control ECO™ / ECO™ Off / Work modes |
Power Steering |
Dynamic Power Steering (DPS) |
SUSPENSION |
|
Front Suspension - |
|
HD5 & HD8 |
Double A-arm / 10 in. (25.4 cm) travel |
HD10 |
Arched double A-arm / 11 in. (27.9 cm) travel |
Front Shocks |
Twin tube gas charged shocks |
Rear Suspension - |
|
HD5 & HD8 |
TTA with external sway bar / 10 in. (25.4 cm) travel |
HD10 |
Arched TTA with external sway bar / 11 in. (27.9 cm) travel |
Rear Shocks |
Twin tube gas charged shocks |
TIRES & WHEELS |
|
Front Tires - |
|
HD5 |
Maxxis M923J† 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm) |
HD8 & HD10 |
Maxxis Bighorn 2.0† 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm) |
Rear Tires - |
|
HD5 |
Maxxis M924J† 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm) |
HD8 & HD10 |
Maxxis Bighorn 2.0† 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm) |
Wheels - |
|
HD5 |
12 in. (30.5 cm) cast-aluminum |
HD8 & HD10 |
14 in. (35.6 cm) cast-aluminum |
BRAKES |
|
Front |
Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
Rear - |
|
HD5 |
Single 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
HD8 & HD10 |
Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers |
DIMENSIONS & CAPACITIES |
|
L x W x H |
HD5-HD8 - 121 x 62 x 76 in. (307.1 x 157.5 x 193 cm) / HD10 - 121 x 64 x 78 in. (307.1 x 162.5 x 198.1 cm) |
Wheelbase |
83 in. (211.5 cm) / 85 in. (211.5 cm) |
Ground Clearance |
HD5 - 10.5 in. (26.7 cm) / HD8 - 11 in. (28 cm) / HD10 - 13 in. (33 cm) |
Chassis Cage |
Profiled cage. ROPS approved |
Dry Weight |
HD5 -1,322.8 lb (600 kg) HD8 - 1,521.2 lb (690 kg) / HD10 - 1,536.6 lb (697 kg) |
Cargo Box Dimensions |
38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm) |
Cargo Box Capacity |
HD5 - 600 lb (272.2 kg) / HD8-HD10 - 1,000 lb (454 kg) / California only |
Tailgate Load Capacity |
250 lb (113.4 kg) |
Storage Capacity |
Total - 10.4 gal (39.5 L) |
Towing Capacity |
HD5 - 1,500 lb (680 kg) / HD8-HD10 - 2,500 lb (1134 kg) |
Payload Capacity |
HD5 - 1,200 lb (544 kg) / HD8-HD10 - 1,500 lb (680 kg) |
Fuel Capacity |
10.6 gal (40 L) |
Person Capacity |
3 |
