ENGINE |
|
Engine Type - |
|
HD5 |
38 hp, Rotax® 427 cc single cylinder, liquid cooled |
HD8 |
50 hp/50 lb-ft, Rotax® 799.9 cc, V-twin, liquid cooled |
Fuel Delivery System |
Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
Transmission - |
|
HD5 |
CVT, P/R/N/H/L, standard engine braking |
HD8 |
PRO-TORQ Transmission with Quick Response System (QRS), high-airflow ventilation and Electronic Drive Belt Protection, Extra-L/H/N/R/P |
Drive Train - |
|
HD5 |
Selectable 2WD/4WD with Visco-Lok† auto-locking front differential |
HD8 |
Selectable Turf Mode/2WD/4WD with Visco-Lok† auto-locking front differential |
Driving Assistance |
Electronic Hill Descent Control ECO™/ECO™ Off/Work modes |
Power Steering |
N/A |
SUSPENSION |
|
Front Suspension |
Double A-arm/10 in. (25.4 cm) travel |
Front Shocks |
Twin tube gas charged shocks |
Rear Suspension |
TTA with external sway bar/10 in. (25.4 cm) travel |
Rear Shocks |
Twin tube gas charged shocks |
TIRES & WHEELS |
|
Front Tires - |
|
HD5 |
Maxxis M923J† 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm) |
HD8 |
Maxxis Bighorn 2.0 27 x 9 x 12 in. (68.6 x 22.9 x 30.5 cm) |
Rear Tires - |
|
HD5 |
Maxxis M924J† 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm) |
HD8 |
Maxxis Bighorn 2.0 27 x 11 x 12 in. (68.6 x 27.9 x 30.5 cm) |
Wheels |
12 in. (30.5 cm) steel |
BRAKES |
|
Front |
Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
Rear - |
|
HD5 |
Single 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
HD8 |
Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers |
DIMENSIONS & CAPACITIES |
|
Chassis/Cage |
Profiled cage, ROPS approved |
Estimated Dry Weight |
HD5 - 1,305.1 lb (592 kg) / HD8 - 1,459.5 lb (662 kg) |
L x W x H |
121 x 62 x 76 in. (307.1 x 157.5 x 193 cm) |
Wheelbase |
83 in. (211.5 cm) |
Ground Clearance |
HD5 - 600 lb (272.2 kg) / HD8 -1,000 lb (454 kg) / California only |
Cargo Box Dimensions |
38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm) |
Power Tilt Bed |
N/A |
Tailgate Load Capacity |
250 lb (113.4 kg) |
Storage Capacity |
Total - 3.1 gal (11.7 L) |
Towing Capacity |
HD5 - 1,500 lb (680 kg) / HD8 - 2,500 lb (1134 kg) |
Payload Capacity |
HD5 - 1,200 lb (544 kg) / HD8 - 1,500 lb (680 kg) |
Fuel Capacity |
10.6 gal (40 L) |
Person Capacity |
3 |
