| Engine & Drivetrain | |
|---|---|
| Cooling | Liquid |
| Cylinders Displacement | 999cc |
| Drive System Type | On-Demand True AWD/2WD/VersaTrac Turf Mode |
| Engine Type | ProStar 1000 4-Stroke DOHC Twin Cylinder |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 100 HP |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H |
| Dimensions | |
| Bed Box Dimensions (L x W x H) | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
| Box Capacity | 600 lb (272 kg) Rear Dumping Box |
| Estimated Dry Weight | 1,712 lb (776.5 kg) |
| Fuel Capacity | 9.5 gal (35.9 L) |
| Ground Clearance | 13.5 in (34.3 cm) |
| Overall Vehicle Size (L x W x H) | 118.2 x 64 x 75 in (300 x 162.5 x 190.5 cm) |
| Payload Capacity | 1,100 lb (499 kg) |
| Person Capacity | 2 |
| Stance | 64 in (162.56 cm) |
| Wheelbase | 83 in (211 cm) |
| Brakes | |
| Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
| Parking Brake | Park In-Transmission |
| Additional Specifications | |
| Cargo System | Lock & Ride |
| Front Shocks | Walker Evans Velocity Series Piggyback Shocks |
| Front Suspension | Long Travel, High Clearance Dual A-Arm with Stabilizer Bar, 14 |
| Rear Shocks | Walker Evans Velocity Series Piggyback Shocks |
| Rear Suspension | Long Travel, High Clearance Dual Arm IRS with Stabilizer Bar, 14 |
| Hitch Towing Rating | 1,500 lb (680.4 kg) |
| Hitch Type | Standard 2 in (5 cm) Receiver |
| Instrumentation | Dual-sweep Analog Dials w/ 4 in LCD Rider Information Center; User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Lighting | LED Headlight w/ Accent & LED Taillights |
| Seat Type | Bolstered Bucket Seats with Driver Seat Slider and Height Adjustable Seat Belts |
| Tires / Wheels | |
| Electronic Power Steering | High Output EPS |
| Front Tires | 30 x 10-15; Pro Armor Crawler XG |
| Rear Tires | 25 x 10-12; 489 |
| Wheels | 30 x 10-15; Pro Armor Crawler XG |
