Engine & Drivetrain |
|
Cooling |
Liquid |
Cylinders Displacement |
2 / 952cc |
Drive System Type |
True On-Demand AWD/2WD |
Engine Type |
ProStar SOHC 4-Stroke Twin Cylinder |
Fuel System/Battery |
Electronic Fuel Injection |
Horsepower |
89 HP |
Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft Drive |
Dimensions |
|
Estimated Dry Weight |
970 lb (440 kg) |
Front/ Rear Rack |
200 lb / 300 lb (91 kg / 136 kg) |
Fuel Capacity |
5.25 gal (19.9 L) |
Ground Clearance |
14.5 in (36.8 cm) |
Overall Vehicle Size (L x W x H) |
82.5 x 55 x 49.5 in (209.5 x 140 x 125.7 cm) |
Payload Capacity |
715 lbs (324 kg) (includes operator, cargo and accessories) |
Seat Height |
37 in (94 cm) |
Wheelbase |
56.8 in (144.27 cm) |
Brakes |
|
Front/Rear Brakes |
Single Lever 4-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake |
Park In-Transmission / Lockable Hand Lever |
Additional Specifications |
|
Cargo System |
Lock & Ride 4 Gal (15L) Front, 2 Gal (8L) Rear |
Front Suspension |
Sealed Dual A-Arm 11.6 in (29.5 cm) Travel |
Rear Suspension |
Sealed Dual A-Arms Rolled IRS, 14 in (35.6 cm) Travel |
Hitch Towing Rating |
1,750 lb (794 kg) |
Hitch Type |
Standard 2 in (5 cm) Receiver |
Instrumentation |
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Lighting |
Halogen Triple 50W High Beams Dual 50w Low Beam Headlight Triple LED Brakelights/Taillights |
Tires / Wheels |
|
Electronic Power Steering |
Not Equipped |
Front Tires |
27 x 9 Duro PowerGrip V2 |
Rear Tires |
27 x 11 Duro PowerGrip V2 |
Wheels |
14 in Aluminum |
