Engine & Drivetrain |
|
Cooling |
Liquid |
Cylinders Displacement |
2 / 850cc |
Drive System Type |
True On-Demand AWD/2WD |
Engine Type |
ProStar 4-Stroke SOHC Twin Cylinder |
Fuel System/Battery |
Electronic Fuel Injection |
Horsepower |
78 HP |
Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
Dimensions |
|
Estimated Dry Weight |
804 lb (365 kg) |
Front/ Rear Rack |
120 lb /240 lb (55 kg / 110 kg) |
Fuel Capacity |
5.25 gal (19.9 L) |
Ground Clearance |
11.25 in (28.5 cm) |
Overall Vehicle Size (L x W x H) |
84.3 x 48.2 x 48.8 in (214 x 123 x 124 cm) |
Payload Capacity |
575 lb (261 kg) |
Seat Height |
35.75 in (90.8 cm) |
Wheelbase |
57 in (144.8 cm) |
Brakes |
|
Front/Rear Brakes |
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake |
Park In-Transmission / Lockable Hand Lever |
Additional Specifications |
|
Cargo System |
Lock & Ride, 2 Gal (8 L) Rear Storage |
Front Suspension |
Straight Dual A-Arm, 9 in. (22.9 cm) Travel |
Rear Suspension |
Straight Dual A-Arm, IRS 10.25 in. (26 cm) Travel |
Hitch Towing Rating |
1,500 lb (680.4 kg) |
Hitch Type |
Standard 1.25 in (3.2 cm) Receiver |
Instrumentation |
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Lighting |
50w High Beam, Dual 50w Low Beam Headlights, Dual Brakelights/Taillights |
Tires / Wheels |
|
Electronic Power Steering |
Not Equipped |
Front Tires |
26 x 8 CST |
Rear Tires |
26 x 10 CST |
Wheels |
14 in Aluminum |
