| Engine & Drivetrain | |
|---|---|
| Cooling | Liquid |
| Cylinders Displacement | 500cc |
| Drive System Type | True On-Demand AWD/2WD |
| Engine Type | ProStar 500cc, 4-Stroke SOHC Single Cylinder |
| Fuel System/Battery | Electronic Fuel Injection |
| Horsepower | 33 HP |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H; Shaft |
| Dimensions | |
| Estimated Dry Weight | 701 lb (318 kg) |
| Front/ Rear Rack | 90 lb /180 lb (40.8 kg /81.6 kg) |
| Fuel Capacity | 4.5 gal (17.0 L) |
| Ground Clearance | 10.5 in (26.7 cm) |
| Overall Vehicle Size (L x W x H) | 83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm) |
| Payload Capacity | 485 lb (220 kg) |
| Seat Height | 33.25 in (84.5 cm) |
| Wheelbase | 50.5 in (128.3 cm) |
| Brakes | |
| Front/Rear Brakes | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
| Parking Brake | Park In-Transmission / Lockable Hand Lever |
| Additional Specifications | |
| Cargo System | Lock & Ride, 6 Gal (23 L) Front Dry Storage, 2 Gal (8 L) Rear Storage |
| Front Suspension | MacPherson Strut With 8.2 in (20.8 cm) Travel |
| Rear Suspension | Dual A-Arm, IRS 9.5 in (24.1 cm) Travel |
| Hitch Towing Rating | 1,225 lb (555.7 kg) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
| Lighting | 50w High Beam, Dual 50w Low Beam Headlights, Dual Brakelights/Taillights |
| Tires / Wheels | |
| Electronic Power Steering | Not Equipped |
| Front Tires | 24 x 8-12; NS388 |
| Rear Tires | 24 x 10-12; NS388 |
| Wheels | Stamped Steel |
