| ENGINE | |
|---|---|
| Engine Type | 4-stroke, single cylinder |
| Displacement | 695cc |
| Cooling System | liquid-cooled |
| Bore x Stroke | 4.02x3.35 in |
| Compression Ratio | 10.3 |
| Fuel System | DFI® with 44mm throttle body |
| Ignition | SOHC |
| DRIVETRAIN | |
| Transmission | Continuously Variable Transmission (CVT) with centrifugal clutch, (H,L,N,R) |
| Final Drive | Selectable 2WD/4WD, shaft. Dual mode rear differential with differential lock |
| SUSPENSION | |
| Suspension Front | Double wishbone |
| Suspension Rear | Double wishbone |
| BRAKES | |
| Front Breaking System | Dual Disc, 2 piston caliper |
| Rear Braking System | Dual Disc, 1 piston caliper |
| WHEELS & TIRES | |
| Front Tire | 25x10.00-12, radial |
| Front Wheel Travel | 8.6 in |
| Rear Tire | 25x10.00-12, radial |
| Rear Wheel Travel | 9.1 in |
| DIMENSIONS | |
| Overall Length | 110.0 in |
| Overall Width | 60.0 in |
| Overall Height | 74.4 in |
| Ground Clearance | 10.6 in |
| Wheelbase | 78.9 in |
| Fuel Tank Capacity | 9.5 gal |
| Curb Weight | 1587.6 lb |
| Cargo Bed Dimensions (LxWxH) | 33.4 x 44.1 x 9.1 in |
| CAPABILITY | |
| Turning Radius | 14.0 ft |
| Towing Capacity | 1500 lb |
| Cargo Bed Capacity | 700 lb (600 lb California models) |
| Load Capacity | 1200 lb |
| Seating Capacity | 2 |
| Lighting | (2) Halogen headlights, (2) LED headlights |
| Maximum Torque | 42.7 lb-ft @ 5000 rpm |
