ENGINE |
|
Engine Type |
4-stroke, 2-cylinder, DOHC, 4 valves per cylinder parallel twin |
Displacement |
649cc |
Cooling System |
Liquid-cooled |
Bore |
83.0 mm |
Stroke |
60.0 mm |
Compression Ratio |
10.8 |
Fuel System |
DFI® with 38mm Keihin throttle bodies (2) |
Ignition |
TCBI with digital advance |
DRIVETRAIN |
|
Transmission |
6-speed with positive neutral finder |
Final Drive |
Sealed chain |
CHASSIS |
|
Frame Type |
Double pipe diamond frame constructed from high-tensile steel |
SUSPENSION |
|
Front Suspension |
41mm hydraulic telescopic fork with stepless adjustable rebound and preload |
Rear Suspension |
Single offset laydown shock with remote adjustable spring preload |
BRAKES |
|
Front braking system |
Dual 300mm petal-style discs with 2-piston calipers, ABS |
Rear braking system |
Single 250mm petal-style disc with single-piston caliper, ABS |
WHEELS & TIRES |
|
Front Tire |
120/70 ZR17 |
Front Wheel Travel |
5.9 in |
Rear Tire |
160/60 ZR17 |
Rear Wheel Travel |
5.7 in |
DIMENSIONS |
|
Rake/trail |
25°/4.3 in |
Overall Length |
85.2 in |
Overall Width |
33.1 in |
Overall Height |
55.1 in/57.1 in (windshield down/up) |
Ground Clearance |
6.7 in |
Seat Height |
33.1 in |
Wheelbase |
55.7 in |
Fuel Capacity |
5.5 gal |
Curb Weight |
476.3 lb |
