| ENGINE | |
|---|---|
| Engine Type | 4-stroke, 4 cylinder, DOHC, 4-valve |
| Displacement | 998cc |
| Cooling system | liquid-cooled |
| Bore x Stroke | 76.0 x 55.0mm |
| Compression Ratio | 13.0 |
| Fuel System | DFI® w/47mm Mikuni throttle bodies (4) with oval sub-throttles, two injectors per cylinder |
| Ignition | TCBI with digital advance and Sport-Kawasaki Traction Control (S-KTRC) |
| DRIVETRAIN | |
| Transmission | 6-speed, return shift |
| Final Drive | Sealed chain |
| CHASSIS | |
| Frame Type | Aluminum perimeter |
| SUSPENSION | |
| Front Suspension | 43mm inverted Balance Free Fork, adjustable stepless rebound and compression damping, spring preload adjustability |
| Rear Suspension | Horizontal back-link with Balance Free gas-charged shock, stepless, dual-range (low-/high-speed) compression damping, stepless rebound damping, fully adjustable spring preload |
| BRAKES | |
| Front Braking System | Intelligent Braking (KIBS), Brembo dual semi-floating 330mm discs with dual radial mounted monobloc 4-piston calipers |
| Rear Braking System | KIBS-controlled, single 220mm disc with aluminum single-piston caliper |
| WHEELS & TIRES | |
| Front Tire | 120/70 ZR17 |
| Front Wheel Travel | 4.7 in |
| Rear Tire | 190/55 ZR17 |
| Rear Wheel Travel | 4.5 in |
| DIMENSIONS | |
| Rake/ Trail | 25.0/4.2 in |
| Overall Length | 82.1 in |
| Overall Width | 29.1 in |
| Overall Height | 45.1 in |
| Ground Clearance | 5.7 in |
| Seat Height | 32.9 in |
| Wheelbase | 56.7 in |
| Fuel Capacity | 4.5 gal |
| Curb Weight | 454.2 lb |
