| ENGINE | |
|---|---|
| Engine Type | 4-stroke, In-Line Four |
| Displacement | 1,043cc |
| Cooling System | liquid-cooled |
| Bore x Stroke | 77.0 x 56.0mm |
| Compression Ratio | 11.8 |
| Fuel system | DFI® w/38mm electronic throttle valves |
| Ignition | TCBI with digital advance |
| DRIVETRAIN | |
| Transmission | 6-speed, return shift |
| Final Drive | Sealed Chain |
| CHASSIS | |
| Frame Type | Aluminum backbone |
| SUSPENSION | |
| Front Suspension | 41mm inverted cartridge fork with stepless compression and rebound damping, adjustable spring preload |
| Rear Suspension | Horizontal monoshock with stepless rebound damping, remotely adjustable spring preload |
| BRAKES | |
| Front Braking System | Front Dual 300mm Semi Floating Discs with Radial Mounted, Monobloc Opposed 4-Piston Calipers, ABS |
| Rear Braking System | Single 250mm Disc, ABS |
| WHEELS & TIRES | |
| Front Tire | 120/70 ZR17 |
| Front Wheel Travel | 4.7 in |
| Rear Tire | 190/50 ZR17 |
| Rear Wheel Travel | 5.4 in |
| DIMENSIONS | |
| Rake/ Trail | 24.0/3.9 in |
| Overall Length | 82.7 in |
| Overall Width | 32.5 in |
| Overall Height | 46.7 / 48.6 in (windshield high) |
| Ground Clearance | 5.3 in |
| Seat Height | 32.1 in |
| Wheelbase | 56.7 in |
| Fuel Capacity | 5.0 gal |
| Curb Weight | 513.8 lb US / 516 lb CA |
