| ENGINE | |
|---|---|
| Engine Type | 4-stroke, 4-cylinder, DOHC, 4-valve |
| Displacement | 1,352cc |
| Cooling System | Liquid-cooled |
| Bore | 84.0 mm |
| Stroke | 61.0 mm |
| Compression Ratio | 10.7 |
| Fuel System | DFI® with 40mm throttle bodies (4) |
| Ignition | TCBI with digital advance |
| DRIVETRAIN | |
| Transmission | 6-speed |
| Final Drive | Tetra-Lever shaft drive |
| CHASSIS | |
| Frame Type | Monocoque Aluminum |
| SUSPENSION | |
| Front Suspension | 43mm inverted, telescopic fork with adjustable rebound damping and spring preload |
| Rear Suspension | Tetra-Lever with stepless rebound damping adjustment and remote spring preload adjuster |
| BRAKES | |
| Front braking system | Dual floating 310mm petal-style discs with four-piston calipers, ABS |
| Rear braking system | Single 270mm petal-style disc, single-piston caliper, ABS |
| WHEELS & TIRES | |
| Front Tire | 120/70 ZR-17 |
| Front Wheel Travel | 4.4 in |
| Rear Tire | 190/50 ZR-17 |
| Rear Wheel Travel | 5.4 in |
| DIMENSIONS | |
| Rake/trail | 26.0°/4.4 in |
| Overall Length | 87.8 in |
| Overall Width | 31.1/39.4 wo/w saddlebags |
| Overall Height | 52.9 in/57.7 in (windshield down/up) |
| Ground Clearance | 4.9 in |
| Seat Height | 32.1 in |
| Wheelbase | 59.8 in |
| Fuel Capacity | 5.8 gal |
| Curb Weight | 690.2 lb (672.5 w/o saddlebags) |
