BRAKES/WHEELS/TIRES |
|
Front Brakes |
(2) 320 mm semi-floating discs, radially mounted Brembo monobloc Evo M50 4- piston calipers, 2-pad, radial pump with Bosch Cornering ABSRear - 265 mm disc, 2-piston floating caliper with Bosch Cornering ABS |
Front Wheels |
3-spoke forged light alloy; 3.50 x 17 in. |
Rear Wheels |
3-spoke forged light alloy, 6.0 x 17 in. |
Rear Tires |
Pirelli Scorpion Trail II 120/70 R17 |
Rear Tires |
Pirelli Scorpion Trail II 190/55 R17 |
DIMENSIONS |
|
Dry Weight |
454 lb. (206 kg) |
Wheelbase |
62.4 in. (1,585 mm) |
Seat Height |
Adjustable - 32.5 to 33.3 in. (825 to 845 mm) |
DRIVETRAIN |
|
Transmission |
6-speed gearbox with Ducati Quick Shift (DQS) up / down |
Final Drive |
Chain, front sprocket 15, rear sprocket 40 |
ELECTRICAL |
|
Lighting |
Full LED headlamp |
ENGINE |
|
Engine |
Ducati Testastretta DVT with Desmodromic variable timing, L-twin cylinder, 4 valves per cylinder, dual spark |
Cooling |
Liquid |
Horsepower |
155 hp (116.2 kW) @ 9,500 rpm |
Displacement |
1,262 cc |
Bore x Stroke |
4.17 x 2.81 in. (106 x 71.5 mm) |
Torque |
95.5 ft. lb. (129.5 Nm) @ 7,500 rpm |
Compression Ratio |
13-1 |
Clutch |
Light action, wet, multi-plate with hydraulic control, self-servo action on drive, slipper action on over-run |
Fuel System |
Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm |
Exhaust |
Stainless steel muffler with catalytic converter and 2 lambda probes, Termignoni carbon fibre silencer |
Fuel Capacity |
5.3 gal. (20 l) |
OPERATIONAL |
|
Frame |
Tubular steel trellis |
Travel |
6.7 in. (170 mm) |
Rear Suspension |
|
Rake |
25° |
Trail |
4.37 in. (111 mm) |
OTHER |
|
Standard equipment |
Cruise control, Hands-Free, backlit handlebar switches, Ducati Multimedia System (DMS), auto-off indicators |
Safety equipment |
Vehicle Hold Control (VHC), riding modes, power modes, Ducati Safety Pack (Bosch Cornering ABS + DTC), Ducati Wheelie Control (DWC), Ducati Cornering Lights |
