| BRAKES/WHEELS/TIRES | |
|---|---|
| Front Brakes | (2) 320 mm semi-floating discs, radially mounted Brembo monobloc Evo M50 4- piston calipers, 2-pad, radial pump with Bosch Cornering ABSRear - 265 mm disc, 2-piston floating caliper with Bosch Cornering ABS |
| Front Wheels | 3-spoke forged light alloy; 3.50 x 17 in. |
| Rear Wheels | 3-spoke forged light alloy, 6.0 x 17 in. |
| Rear Tires | Pirelli Scorpion Trail II 120/70 R17 |
| Rear Tires | Pirelli Scorpion Trail II 190/55 R17 |
| DIMENSIONS | |
| Dry Weight | 454 lb. (206 kg) |
| Wheelbase | 62.4 in. (1,585 mm) |
| Seat Height | Adjustable - 32.5 to 33.3 in. (825 to 845 mm) |
| DRIVETRAIN | |
| Transmission | 6-speed gearbox with Ducati Quick Shift (DQS) up / down |
| Final Drive | Chain, front sprocket 15, rear sprocket 40 |
| ELECTRICAL | |
| Lighting | Full LED headlamp |
| ENGINE | |
| Engine | Ducati Testastretta DVT with Desmodromic variable timing, L-twin cylinder, 4 valves per cylinder, dual spark |
| Cooling | Liquid |
| Horsepower | 155 hp (116.2 kW) @ 9,500 rpm |
| Displacement | 1,262 cc |
| Bore x Stroke | 4.17 x 2.81 in. (106 x 71.5 mm) |
| Torque | 95.5 ft. lb. (129.5 Nm) @ 7,500 rpm |
| Compression Ratio | 13-1 |
| Clutch | Light action, wet, multi-plate with hydraulic control, self-servo action on drive, slipper action on over-run |
| Fuel System | Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm |
| Exhaust | Stainless steel muffler with catalytic converter and 2 lambda probes, Termignoni carbon fibre silencer |
| Fuel Capacity | 5.3 gal. (20 l) |
| OPERATIONAL | |
| Frame | Tubular steel trellis |
| Travel | 6.7 in. (170 mm) |
| Rear Suspension | |
| Rake | 25° |
| Trail | 4.37 in. (111 mm) |
| OTHER | |
| Standard equipment | Cruise control, Hands-Free, backlit handlebar switches, Ducati Multimedia System (DMS), auto-off indicators |
| Safety equipment | Vehicle Hold Control (VHC), riding modes, power modes, Ducati Safety Pack (Bosch Cornering ABS + DTC), Ducati Wheelie Control (DWC), Ducati Cornering Lights |
